Tungsten Alloy Spacecraft Gyro Stabilizer Counterweight
High-purity W-Ni-Fe / W-Ni-Cu counterweight for control moment gyroscopes (CMGs) and reaction wheels — 18.0–18.5 g/cm³, ≤ 0.002 mm concentricity, ISO G0.4 balance, outgassing approved for deep space.
- Materials
- High-purity W-Ni-Fe / W-Ni-Cu
- Features
- Sub-micron concentricity ≤ 0.002 mm, void-free high-vacuum sintered matrix, maximized gyro bearing lifespan, optimal rotational inertia
- Application
- Control moment gyroscopes (CMGs), reaction wheels, high-speed spacecraft stabilization systems.
Specifications
| Parameter | Value |
|---|---|
| Material Grade | High-Purity W-Ni-Fe / W-Ni-Cu |
| Sintered Density | 18.0 – 18.5 g/cm³ |
| Concentricity | ≤ 0.002 mm |
| Dynamic Balance | ISO G0.4 |
| Vacuum Stability | Outgassing Approved |
Frequently Asked Questions
What materials and process are used for Tungsten Alloy Spacecraft Gyro Stabilizer Counterweight?
Tungsten Alloy Spacecraft Gyro Stabilizer Counterweight is made from High-purity W-Ni-Fe / W-Ni-Cu and is formed by MIM/PM (metal injection molding / powder metallurgy) near-net-shape and sintered to a relative density of ≥ 98%, which keeps mechanical properties close to wrought material.
What are the key specifications of Tungsten Alloy Spacecraft Gyro Stabilizer Counterweight?
Typical specifications: Material Grade: High-Purity W-Ni-Fe / W-Ni-Cu; Sintered Density: 18.0 – 18.5 g/cm³; Concentricity: ≤ 0.002 mm. The full parameter list is in the specifications table on this page; custom requirements can be discussed against your drawing.
What is the MOQ and lead time for Tungsten Alloy Spacecraft Gyro Stabilizer Counterweight?
MOQ is 1000 pcs. Mold lead time is about 20 days (mold fee typically RMB 20–40k depending on part geometry), and production lead time is about 7 days once the mold is validated; secondary processing adds 3–5 days.
